MAX6514/MAX6515
Low-Cost, 2.7V to 5.5V Temperature Switches
in a SOT23
_______________________________________________________________________________________ 3
TRIP THRESHOLD ACCURACY
MAX6514 toc01
ACCURACY (°C)
PERCENTAGE OF PARTS SAMPLED (%)
-0.25 TO
-0.5
-0.75 TO
-1.0
10
20
30
40
50
0
-1.25 TO
-1.5
0.25 TO
0.5
0.75 TO
1.0
1.25 TO
1.5
SAMPLE SIZE = 147
SUPPLY CURRENT
vs. TEMPERATURE
MAX6514 toc02
TEMPERATURE (°C)
SUPPLY CURRENT (
µ
A)
105 85 65 45 25 5 -15 -35
5
10
15
20
25
30
0
-55 125
TOVER/TUNDER OUTPUT VOLTAGE HIGH
vs. SOURCE CURRENT
MAX6514 toc03
I SINK (mA)
V
OH
(V)
9 8 7 6 5 4 3 2 1
1
2
3
4
5
0
0 10
MAX6514 toc04
I SINK (mA)
V
OL
(V)
9 8 7 6 5 4 3 2 1
100
200
300
400
500
0
0 10
TOVER/TUNDER OUTPUT VOLTAGE LOW
vs. SINK CURRENT
STARTUP AND POWER-DOWN (TEMP < T TH )
MAX6514 toc05
TIME (400µs/div)
V CC
(2V/div)
TOVER
(2V/div)
STARTUP DELAY (TEMP > T TH )
MAX6514 toc06
TIME = 100µs
V CC
(2V/div)
TOVER
(2V/div)
Typical Operating Characteristics
(V
CC
= 4.5V, T
A
= +25°C, unless otherwise noted.)
