Electrical Characteristics
(Continued)
The following specifications apply for V
CC e a 5 0V V
REF e a 4 6V f
S e 700 kHz and f
C e 3 MHz unless otherwise
specified Boldface limits apply for T A e T J e T MIN to T MAX all other limits T A e T J e 25 C
Symbol Parameter Conditions
Typical Limit Units
(Note 8) (Note 9) (Limits)
DIGITAL AND DC CHARACTERISTICS
V IN(1) Logical ‘‘1’’ Input Voltage V CC e 5 25 V DC 2 0 V (min)
V
IN(0)
Logical ‘‘0’’ Input Voltage V
CC e 4 75 V
DC
0 8 V (max)
I
IN(1)
Logical ‘‘1’’ Input Current V
IN e 5 0 V
DC
0 005 2 5 m A (max)
I IN(0) Logical ‘‘0’’ Input Current V IN e 0 V DC b 0 005 b 2 5 m A (max)
V OUT(1) Logical ‘‘1’’ Output Voltage V CC e 4 75 V DC
I
OUT e b 360 mA 2 4 V (min)
I
OUT e b 10 mA 4 5 V (min)
V
OUT(0)
Logical ‘‘0’’ Output Voltage V
CC e 4 75 V
DC
0 4 V (max)
I
OUT e 1 6 mA
I
OUT
TRI-STATE Output Current V
OUT e 0V b 0 01 b 3 m A (max)
V OUT e 5V 0 01 3 m A (max)
I SOURCE Output Source Current V OUT e 0V b 14 b 6 5 mA (min)
I SINK Output Sink Current V OUT e V CC 16 8 0 mA (min)
I
CC
Supply Current CS e HIGH V
REF
Open 1 5 3 mA (max)
AC CHARACTERISTICS
f C Conversion Clock (C CLK ) 0 7 MHz (min)
Frequency 4 0 3 0 MHz (max)
f
S
Serial Data Clock (S
CLK
) f
C e 3 MHz R L e ‘‘0’’ 183 kHz (min)
Frequency (Note 13) f C e 3 MHz R L e ‘‘1’’ 622 kHz (min)
f C e 3 MHz R L e ‘‘0’’ or R L e ‘‘1’’ 2 1 0 MHz (max)
T C Conversion Time Not Including MUX Addressing and 41 (1 f C )
(max)
Analog Input Sampling Times a 200 ns
t CA Analog Sampling Time After Address is Latched CS e Low 4 5 (1 f S )
(max)
a 200 ns
t ACC Access Time Delay from CS or OE OE e ‘‘0’’
100 200 ns (max)
Falling Edge to DO Data Valid
t SET-UP Set-up Time of CS Falling
75 150 ns (min)
Edge to S CLK Rising Edge
t 1H t 0H Delay from OE or CS Rising R L e 3 kX C L e 100 pF
100 120 ns (max)
Edge to DO TRI-STATE
t HDI DI Hold Time from S CLK Rising Edge 0 50 ns (min)
t SDI DI Set-up Time to S CLK Rising Edge 50 100 ns (min)
