MAX6576/MAX6577
SOT Temperature Sensors with
Period/Frequency Output
_______________________________________________________________________________________ 3
0
10
5
15
20
25
30
35
-5 -3 -2 -4 -1 0 1 2 3 4 5
TEMPERATURE ACCURACY
(T A = +25 ° C)
MAX6576 toc01
ACCURACY ( ° C)
PERCENTAGE OF PARTS SAMPLED (%)
MAX6576
MAX6577
SAMPLE SIZE = 200
0
20
10
30
40
50
60
-5 -3 -2 -4 -1 0 1 2 3 4 5
TEMPERATURE ACCURACY
(T A = +85°C)
MAX6576 toc01
ACCURACY (°C)
PERCENTAGE OF PARTS SAMPLED (%)
MAX6576
MAX6577
SAMPLE SIZE = 200
100
130
120
110
150
140
170
160
180
-40 -10 5 20 -25 35 50 65 80 95 110 125
SUPPLY CURRENT vs. TEMPERATURE
MAX6576/77toc02
TEMPERATURE ( ° C)
SUPPLY CURRENT (
µ
A)
MAX6577
MAX6576
-1.0
0
-0.5
1.0
0.5
1.5
-40 -10 5 20 -25 35 50 65 80 95 110 125
ACCURACY vs. TEMPERATURE
MAX6575 toc04
TEMPERATURE ( ° C)
ACCURACY (
° C)
MAX6576
MAX6577
+15 ° C/div
+100 ° C
+25 ° C
THERMAL STEP RESPONSE
IN PERFLUORINATED FLUID
MAX6576/77 toc05
5sec/div
MOUNTED ON 0.75 in. 2
OF 2oz. COPPER
+12.5 ° C/div
+100 ° C
+25 ° C
THERMAL STEP RESPONSE
IN STILL AIR
MAX6576/77 toc06
20sec/div
MOUNTED ON 0.75 in. 2
OF 2oz. COPPER
Typical Operating Characteristics
(V
DD
= +5V, T
A
= +25°C, unless otherwise noted.)
