NUC100 Series DATA SHEET
Publication Release Date: May 31, 2010
- 8 - Revision V1.02
• I 2 C
– Two sets of I 2 C device.
– Master/Slave up to 1Mbit/s ( Fast-mode Plus )
– Bidirectional data transfer between masters and slaves
– Multi-master bus (no central master).
– Arbitration between simultaneously transmitting masters without corruption of serial data on
the bus
– Serial clock synchronization allows devices with different bit rates to communicate via one
serial bus.
– Serial clock synchronization can be used as a handshake mechanism to suspend and resume
serial transfer.
– Programmable clocks allow versatile rate control.
– I2C-bus controllers support multiple address recognition ( two slave address with mask option)
• I 2 S
– Interface with external audio CODEC
– Operate as either master or slave mode
– Capable of handling 8, 16, and 32 bit word sizes
– Mono and stereo audio data supported
– I 2 S and MSB justified data format supported
– Two 8 word FIFO data buffers are provided, one for transmit and one for receive
– Generates interrupt requests when buffer levels cross a programmable boundary
– Support two DMA requests, one for transmit and one for receive
• ADC
– 12-bit SAR ADC with 800ksps
– Up to 8-ch single-end mode or 4-ch differential mode
– Single scan/single cycle scan/continuous scan
– Each channel with individual result register
– Scan on enabled channels
– Threshold voltage detection
– Conversion start by S/W, external pins
– Support PDMA mode
• Analog Comparator
– Up to 2 comparator analog modules
– External input or internal bandgap voltage selectable at negative node
– Interrupt when compare result change
– Power down wake up
• One built-in temperature sensor with 1℃ resolution.
• Brown-out detector
– With 4 levels: 4.5V/3.8V/2.7V/2.2V
– Support Brownout Interrupt and Reset option
• One built-in LDO
• Low Voltage Reset
• Operating Temperature: -40℃~85℃
• Packages:
– All Green package (RoHS)
‹
LQFP 100-pin / 64-pin / 48-pin
