9021 Owner’s Manual •••• (V 1.1) Page 14 of 22
Card Control and Status
Card Control Switches
The majority of the card control can be performed by the 8 switches on switch bank S1. Their operation
is detailed in the following table.
S1.1-4 VIDEO INPUT AND COLOR SEPARATION MODE
On On On On Composite 4-Line Adaptive Comb
On On On Off Composite 4-Line Non-adaptive Comb
On On Off On Composite 3-Line Adaptive Comb
On On Off Off Composite Notch Filter
On Off xx xx Y/C (S-Video)
Off On On On Component YPbPr BetaCam™
Off On Off Off Component YPbPr MII™
Off On Off On Component YPbPr SMPTE/N10
Off Off On On Component Y only BetaCam™
Off Off Off Off Component Y only MII™
Off Off Off On Component Y only SMPTE/N10
S1.5 MANUAL GAIN CONTROL
OFF Manual gain control enabled
ON Automatic gain control enabled
S1.6 COLOR BARS ON/OFF
OFF Display Video
ON Display Color Bars
S1.7 JITTER FILTER
OFF Jitter Filter Off
ON Jitter Filter On
S1.8 SETUP
OFF Pedestal not removed (recommended for PAL)
ON 7.5 IRE pedestal removed (recommended mode NTSC only)
Other, less used, parameters are adjusted by dialing S3 and S4 to certain values, and then moving the
thumb switch S2 up or down. These parameters are detailed in the following table. For any given parameters,
pressing the REGISTER RESTORE button (S5) will restore the parameter to it’s saved setting.
S3 S4 Internal
0 0 Normal card operation
1 1 Y Gain
1 2 Y Offset (Black level)
1 3 Color Saturation
1 4 Hue (for Composite and Y/C inputs only)
5 1 Luma Peaking Filter adjustment
6 1 Vbit transition (S2 Up = ITU, line 10) (S2 Down = SMPTE, Line 20, Default)
8 8 Restore Factory Defaults (Press S2 Up)
9 9 Save Settings (Press S2 Up)
