Page 14 9001 Owner’s Manual •••• (V 1.8)
The Menu System
The following table and sections describe the menus, items, and parameters available from the
DashBoard Control System software for the card.
Table 3. DashBoard Menus
Menu Item Parameters Description
Product CDI-9001
Manufacturer Cobalt Digital Inc.
Serial Number
############ Displays the Silicon Serial
Number of the card.
Software Release
Number ### The release number of the
firmware in this card
Software Build
Date ### The internal build number
of this software
Temperature
Temperature of on card
sensor
Input Current
Current consumed from
+12V rail
Card Info
(Read-only)
Input Voltage
Measured voltage of +12V
rail
Remote Control Enabled/Disabled
This shows whether the
remote is enabled (S1-1 on
the board is up)
Rate
Automatic
2.967/2970 Gbps
1.4835/1.485Gbps
270 Mbps
This forces the reclocker to
only run at the specified
rate. “Automatic” means
the reclocker will detect
the input rate and reclock
it.
Reclocker On/Off
Enables or Disables
Reclocking on all outputs.
Control
Lock Status
Describes the current input
rate
