9032 Owner’s Manual •••• (V 2.1) Page 13 of 26
Proc Saturation
This is Chroma (C channel) gain, expressed as a percentage. It ranges from 0.0% to 200.0% in 0.1%
steps.
Proc Phase
This is Chroma (C channel) phase adjustment, expressed in degrees, ranging from –360 to +360 in
steps of one degree.
Decoder SD Input
Selects the input format for SD analog video. This must be changed to reflect the analog video format
on the input for the 9032 to lock correctly. Valid SD formats are GBR, Component SMPTE,
Component MII, Component Betacam, Component Y/C, and Composite.
Decoder HD Input
Selects the input format for HD analog video. The user must select between GBR and YPbPr for the
9033 to lock to the input correctly.
SD Pedestal (Setup)
Selects between 0 IRE and 7.5 IRE of setup (pedestal)on the input analog SD signal. This tells the card
how much setup needs to be removed from the input.
Select Default Source SDI / Analog
Selects the input that has priority when both SDI and Analog inputs are detected.
AFD Submenu
Menu Structure Parameter Type
Mode —
Code AFD Code on output SDI
AFD
Line VBI line for AFD code on
output SDI
Mode
Selects to either pass, replace, or insert a specified AFD code.
Code
Allows the user to enter an AFD code.
Line
Allows the user to specify the VBI line number where the AFD resides.
