PNEG-1449

Page 5 of 8

4" and 5" Truss Kits for 40' Spans

Tube Truss Kits Parts List

Ref #

Part #

Description

Qty

4"

5"

1

AS-0193

Air System 4" Truss Base Assembly

2

1

AS-0195

Air System 5" Truss Base Assembly

2

2

S-248

Flat Washer 3/8" USS ZN YDP Grade 2

12

12

3

S-9082

Carriage Bolt 3/8"-16 x 2" ZN Grade 5

4

4

4

S-968

Flange Nut 3/8"-16 ZN Grade 5

20

20

5

GK4794

Truss Brace Angle

2

2

6

S-9065

Flange Bolt 3/8"-16 x 1" ZN Grade 5

16

16

7

AS-0185

4" Saddle Weld - Eye Bolt Zinc Plate

2

7

AS-0182

5" Saddle Weld - Eye Bolt Zinc Plate

2

8

S-10115

Eye Bolt 5/8"-11 x 13" Grade 2 ZN Weld

4

4

9

S-858

Flat Washer 5/8" USS ZN

4

4

10

S-7597

Hex Nut 5/8"-11

8

8

11

AS-0192

4" Saddle Assembly - Cable

2

11

AS-0188

5" Saddle Assembly - Cable

2

12

GK2641

Cable: Truss - 5/16" x 45' Long

4

4

13

GK2760

Clamp Cable 5/16"

16

16
