JS500 to DT1500 Hardware
Reference Sheet
When viewing illustrations in the instruction manual PNEG-1000-JS with JS500 part numbers, use the
cross reference chart below to identify the correct DT1500 part number to be used.
JS500 to DT1500 Hardware Reference Guide
Part #
Description
JS500
DT1500
S-7482
S-10214
Flange Bolt 5/16"-18 x 3/4" Grade 8 or Grade 8.2 (Pre-Assembled with
Low Density Poly Sealing Washer)
S-7483
S-10215
Flange Bolt 5/16"-18 x 1-1/4" Full Threaded Grade 8 or Grade 8.2
(Pre-Assembled with Low Density Poly Sealing Washer)
S-7484
S-10216
Hex Nut 5/16"-18 Grade 5
S-7485
S-10217
Flange Bolt 3/8"-16 x 1" Grade 8 or Grade 8.2
S-7486
S-10218
Flange Bolt 3/8"-16 x 1-1/2" Grade 8 or Grade 8.2 (Fully Threaded,
No Sealing Washer)
S-7487
S-10221
Flange Bolt 3/8"-16 x 1" Grade 8 or Grade 8.2 (Pre-Assembled with
Low Density Poly Sealing Washer)
S-7488
S-10219
Flange Bolt 3/8"-16 x 1-1/2" Grade 8 or Grade 8.2 (Pre-Assembled with
Low Density Poly Sealing Washer)
S-7489
S-10222
Hex Nut 3/8"-16 Grade 5
S-9426
S-10220
Flange Nut 3/8"-16
