PNEG-1114 Page 5 of 5
Roof Stair Assembly
40 Series Peak Walkarounds Part List for STR1038 and STR1039
Ref # Part # Description
Qty
For 4' For 5' 4"
1 STR0028 40" Left Roof Stair Post 1 1
2 STR0029 40" Right Roof Stair Post 1 1
3 STR0030 20" Left Roof Stair Post 1 1
4 STR0031 20" Right Roof Stair Post 1 1
5 STR0032 51-1/2" Right Siderail (3 Steps) 1 -
6 STR0033 35" Left Post Brace for Roof Stairs 1 1
7 STR0034 51-1/2" Left Siderail (3 Steps) 1 -
8 STR0035 Roof Stair Step 3 4
9 STR0036 53-1/2" Round Handrail 4 -
10 STR0038 35" Right Post Brace for Roof Stairs 1 1
11 STR0039 67-1/2" Right Siderail (4 Steps) - 1
12 STR0040 67-1/2" Left Siderail (4 Steps) - 1
13 STR0041 68" Round Handrail - 4
14 STX-0355 40 Series 54', 60' and 135' Bin - 6' Peak Walkaround Kickplate - 37"
14 STX-0347 40 Series 72'-105' Bin - 10' Peak Walkaround Kickplate - 53"
15 STX-0351 40 Series 54'-60' Bin - 6' Peak Walkaround Handrail Weldment
15 STX-0341 40 Series 72'-105' Bin - 10' Peak Walkaround Handrail Weldment
15 STX-0381 40 Series 135' Bin - 14' Peak Walkaround Handrail Weldment
16 LDR-4087 Large Intermediate Handrail Winding Stair (Nested and Field Cut to Fit)
17 LDR-4088 Small Intermediate Handrail Winding Stair (Nested and Field Cut to Fit)
18 STX-0353 40 Series 54', 60' and 135' Bin - 6' Peak Handrail - 37-1/2"
18 STX-0343 40 Series 72'-105' Bin - 10' Peak Platform Handrail - 53-1/2"
