| 5
home re-route the starter
cable as shown in Figure
2 .
Reinstall the cable onto the
stud on the starter and tighten
the retaining nut. Secure the
starter cable to the other
cable running through this
area using the steel wire ties
provided. You will not need
the starter cable extension
provided.
19.
If the starter cable runs
from the back of the motor
home install the 90-degree
terminal end of the supplied
starter cable extension onto
the starter motor and tighten
the retaining nut. Route
the starter cable extension
forward through the frame rail
under the cross member then
back over the cross member
to the starter motor and at
least 6” away from all heat
sources as shown in Figure
3 .
Slide the 4-inch length of heat
shrink over the extension.
Attach the extension to the
factory starter cable using
(1)
5 ⁄
16
-18 x 1 ⁄
2
” bolt, (1) 5 ⁄
16
-18
crimplock nut, and (1) 5 ⁄
16
SaE. Slide the heat shrink
over the connection and heat
with a heat gun until the heat
shrink tightly conforms to
the connection. Make sure
the connection is completely
covered.
20.
Inspect the exhaust
mounting surfaces of
the cylinder heads and
remove any rust or carbon,
which would prevent the
TorqueTube manifolds from
sealing. Tie cables away
from left-side Torque Tube as
shown in Figure
4 .
Note: Do not use the factory
exhaust manifold gaskets
upon reinstallation. Banks
TorqueTube manifolds are
a machined surface and are
designed to seal without
gaskets.
21.
apply a small amount
of anti-seize on the threads
of the 8 mm manifold bolts
supplied. Lift the right side
TorqueTube manifold into
place and install one 8 mm
x 25 mm bolt at the front of
the manifold and one at the
rear to hold the TorqueTube
Figure 2
Figure 3
