Banks Power Ford Trucks: (Diesel ’99 - 03 7.3L Power Stroke) Exhaust- Monster Sport Exhaust System '99-03 F-250_350 Pickups - Manual (Page 9)

For Super-cab long-bed: Remove
the rear frame mounted hanger (see
Figure 3) and install the supplied
frame mounted hanger in its place,
using the two 8mm x 30mm hex bolts
supplied and re-using the two 8mm
nuts previously removed. Install the
intermediate pipe. Place a 4” clamp on
the end of the intermediate pipe and
install the extension pipe kit (P/N
53517).
For Crew-cab long-bed: Install
the rear intermediate pipe. Place
a 4” clamp on the end of the rear
intermediate pipe and install the
extension pipe kit (P/N 53518).
6.
Install the single pin front hanger
clamp onto the intermediate pipe with
the hanger pin on the inside facing the
muffler. Insert the hanger pin into the
vehicle’s rubber grommet.
7.
Install the inlet of the Banks
Monster muffler onto the intermediate
pipe. Install the dual pin rear hanger
clamp onto the outlet of the Monster
muffler with the hanger pins on the
inside, facing the muffler. Insert the
two hanger pins into the vehicle’s
rubber grommets. Orient the muffler
such that the Banks logo is visible
from the passenger side.
8.
Install the tailpipe into the outlet of
the Monster muffler. Insert the hanger
pin on the tailpipe into the vehicles’s
rubber grommet.
Note: If installing optional tailpipe
tip, cut off 4” from the tailpipe outlet
before installing the tailpipe into Banks
Monster Muffler. See Figure 4.
Figure 3- For Extension Pipe Kit (P/N 53517)
96572 v.3.0
9
