6
96307 v.7.0
Figure 5 Ford Raptor Model Only
6.
For Ford Raptor models only,
the factory hanger in front of the
muffler will need to be moved forward.
Loosen and remove the bolts on the
factory hanger and remove the Clip-
on-nuts. Install the clip-on-nuts to the
next forward set of factory holes. See
Figure 5. Re-install the hanger using
the factory hardware.
7.
Install the 3” hanger clamp onto the
muffler inlet. The Hanger pin should
face the front of the vehicle. Install
Banks Muffler inlet (Note the inlet
labeling of the muffler) onto the
intermediate pipe and lightly tighten
the 3” hanger clamp.
8.
Install a 3” clamp on the Banks
Muffler outlet. From the vehicle rear,
route the Front Tailpipe over the rear
axle. Start the Front Tailpipe hanger
pin into the corresponding vehicle
rubber hanger. Install the Front
Tailpipe into the Banks Muffler Outlet
(see Figure 6). Loosely tighten the 3”
clamp to secure the Front Tailpipe.
NOTE: Install the rubber hanger pins
to the vehicle frame if previously
removed.
9.
For Ford 2011 3.5L ECO Boost,
install a 3” clamp onto the outlet of
the front tailpipe.
For all other models, Install a 3.5”
clamp onto the outlet of the Front
Tailpipe. Install the Rear Tailpipe
into the Front Tailpipe outlet. Install
the rear factory rubber hanger onto
the rear tailpipe hanger pin. Loosely
tighten the clamp to secure the Rear
Tailpipe. Reinstall the two (2) factory
M8x1.25 bolts through the rubber
hanger into the vehicle frame. See
Figure 2.
10.
Install the band clamp over the
inlet of the Monster tip. Install the
Monster tip and band clamp onto the
rear tailpipe. Loosely tighten the band
clamp to secure the Monster tip. See
Figure 2.
11.
Adjust the tip about 1 ⁄
2
”-1” under
the body panel, such that the position
is aesthetically pleasing.
