9.
For Double Cab Long Bed ONLY
Install the Banks Monster Muffler inlet
onto the Rear Intermediate pipe
For All Other Bed Configurations
Install the Banks Monster Muffler inlet
onto the Front Intermediate pipe
(Note the inlet labeling of the muffler).
Orient the Monster logo such that is
visible from the passenger side and
parallel with the frame rail. Align the
hanger clamp onto the muffler inlet.
NOTE: All clamps should be positioned
at the beginning of the slots (on the
1⁄2 circle punch) and evenly tightened.
10.
Install the 3” dual pin hanger
clamp onto the Banks Muffler outlet
such that the hanger pins are facing
rear. Install the two (2) hanger pins
into the corresponding vehicle rubber
grommets (see Figure 3).
11.
From the vehicle rear, route
the Front Tailpipe over the rear end.
Install the Front Tailpipe into the Banks
Muffler outlet. Lightly tighten the rear
muffler hanger clamp to secure the
Front Tailpipe (see Figure 3).
Install a 3” exhaust clamp onto the
Front Tailpipe outlet. Install the Rear
Tailpipe into the Front Tailpipe outlet.
Loosely tighten the 3” clamp. Start
the Rear Tailpipe hanger pin into the
corresponding vehicle rubber hanger
12.
Adjust the Tailpipe Tip 1⁄2” under
the rear fender such that the tip
position is aesthetically pleasing.
13.
With the exhaust positioned
properly, begin to tighten the clamps
starting with the ones closest to the
front of the vehicle and working your
way back. Torque the exhaust clamps
evenly to 35 ft-lbs. Make sure that
each slip is fully inserted (+/- 1⁄4”).
14.
Remove the protective covering
from the tailpipe tip.
CAUTION: THE PROTECTIVE
COVERING MAY IGNITE AND
BURN IF NOT REMOVED PRIOR TO
RUNNING THE ENGINE.
15.
Your system includes two (2)
Banks Power logos designed to
complement the Toyota Tacoma
emblems on the vehicles front doors.
Use the provided measurements for a
clean factory look (see Figure 4).
16.
Re-connect the negative battery
cable. Start the engine and listen for
exhaust leaks. Tighten the exhaust
clamps as necessary. Whenever
possible, tack weld slip connections
to prevent disengagement is
recommended. The Banks Monster
Exhaust installation is now complete.
