1. The 280781 Receiver works in conjunction with the 280709 HDMI 8x8 Matrix Selector Switch over UTP.
2. Connect dual Cat 5e or Cat 6 cable assemblies from the UTP outputs on the Matrix switch to the UTP
inputs of the 280781 Receiver. Cables should be terminated to TIA T568B and connected respectively to
#1 and #2 inputs and outputs.
3. Connect the HDMI sink (such as HD-LCD HD-DLP) to the Receiver.
4. Connect the IR TX UNIT into the Matrix Switch. Then connect the IR RX UNIT into the Receiver.
5. Connect the IR RX UNIT into the Matrix Switch. Then Connect the IR TX UNIT into the receiver. Doing both
of these combinations provides for downstream and upstream control.
Note: Please insert and extract cables gently.
CONNECT AND OPERATE
Package Contents:
1. 280781 Receiver Unit
2. 5V DC Power Supply
3. IR RX Pigtail
4. Mounting Ears
5. Product Manual
