Page 4
www.vanco1.com
888.769.4156
4
1. The VPW-280781 Receiver works in conjunction with VPW-280709, VPW-280608.
2. Connect dual Cat 5e or Cat 6 cable assemblies from the UTP outputs on the Matrix/Splitter switch
to the UTP inputs of the 280781 Receiver. Cables should be terminated to TIA T568B and connected
respectively to #1 and #2 inputs and outputs.
3. Connect the HDMI sink (such as HD-LCD HD-DLP) to the Receiver.
4. Connect the IR TX UNIT into the Matrix Switch/Splitter. Then connect the IR RX UNIT into the Receiver.
5. Connect the IR RX UNIT into the Matrix Switch/Splitter. Then Connect the IR TX UNIT into the receiver.
Doing both of these combinations provides for downstream and upstream control.
Note: Please insert and extract cables gently.
CONNECT AND OPERATE
Package Contents:
1. 280781 Receiver Unit
2. 5V DC Power Supply
3. IR RX Pigtail
4. Mounting Ears
5. Product Manual
