Cable Preparation Tools
HX-596
Hex Crimp Tool RG-59 and RG-6
z
.262” and .324” Hex Sizes
z
Hardened Steel Jaws
z
Compression Adjustment
HX-596Q
Hex Crimp Tool RG-59, RG-6, and RG-11
z
100”, .324”, and .495” Hex Sizes
z
Hardened Steel Jaws
z
Compression Adjustment
CCT-596
Compression Crimp Tool
This adjustable compression tool is designed
to install most of the industry Compression
type F Connectors.
With an adjustable plunger assembly, it is
easy to adjust this tool for the proper com-
pression distance required for the different
RG-59 and RG-6 connectors such as SNAP-
N-SEAL by T&B, EZF by Raychem, SPL by
Stirling, TAC and ULTRASEAL by Gilbert as
well as others.
The ratchet feature ensures complete com-
pression of the connector.
