Display 2.8”TFT 400 x 240 full color
Weight 1.12 lb (510 g)
Dimensions 6.9 x 3.9 x 2 in / 175 x 100 x 52 mm (H x W x D)
AC Adaptor Input: 100‐240V~ 50‐60Hz Output: 12VDC, 2A
Battery LiIon smart battery (7.2VDC, 2300mAh)
Operating Time > 5 hours
Operating Temperature 23ºF to 104ºF (‐5ºC to 45ºC)
Storage Temperature ‐4ºF to 158ºF (‐20ºC to 70ºC)
Humidity 5% to 95% non‐condensing
Ruggedness Survives 1 m (3 ft) drop to concrete on all sides
Interfaces USB 2.0, RJ45 10/100‐T Ethernet interface for Remote Control,
Storage 400 MB (internal) for measurements
Power up time < 10 seconds
Frequency Range 5 MHz to 1002 MHz
Frequency Resolution 50 kHz
Frequency Tuning Frequency or channel
Input Impedance 75Ω F‐type connector
Spectrum Analyzer Span 2.5, 6.25, 12.5, 25, 62.5, 125, 250, 500 MHz and Full
Spectrum Analyzer Scale 5 and 10 dB/div
Reverse Path Ingress Scan Range Selectable 5 to 42 MHz, 5 to 68 MHz, and 5 to 85 MHz
Reverse Path Ingress Scan Mode Peak, Average, Min, and Real‐time
DIGITAL
Demodulation ITU‐T J.83 Annex A/B/C standard
Support 16, 32, 64, 128 and 256 QAM, QPSK
Symbol Rate 2 to 6.9 MS/sec
DFE filter On / Off
Dynamic Range ‐30 to +60 dBmV
C/N up to 45 dB
MER up to 40 dB
Accuracy ±2 dB
Resolution 0.1 dB
Pre‐BER and Post‐BER (Annex B) 1.0E‐3 to 1.0E‐8
BER (Annex A/C) 1.0E‐3 to 1.0E‐8
Constellation Display 16, 32, 64, 128 and 256 QAM
Constellation Zoom Capability 
Constellation Graphical Representation 
ANALOG
Dynamic Range ‐30 to +60 dBmV
V/A up to 30 dB
C/N up to 45 dB
Accuracy ±2 dB
Resolution 0.1 dB
CSO/CTB 
Channel Plans
Factory Channel Plans Standard CATV, Return, HRC, IRC, Broadcast, CCIR
Custom Channel Plans (Learning Plan) up to 16 channel plans
System Scan Channels up to 100 channels (analog and/or digital)
System Scan Measurements Level bar representation and C/N BER/MER of the selected
Tilt Channels up to 100 channels (analog and/or digital)
Tilt Selectable Markers 
Tilt Factory Profiles Trunk, Tap, End of line, Ground Block, Modem Setup
Tilt Custom Profiles up to 10 profiles
Voltmeter Range 9V to 150V
Voltmeter Accuracy ±1%
Hum Range 2 to 5%
Hum Accuracy ±1%
Digital Measurements
H30
Digital Processing
Handheld QAM Meter
Specifications Subject To Change Without Notice Rev 0-13 ©Toner Cable Equipment, Inc.
TECHNICAL SPECIFICATIONS
