Spectrum Analyzer
Frequency Range 5 MHz ~ 1050 MHz (TV), 950 MHz ~ 2150 MHz (Satellite)
Frequency Span 1 MHz ~ 1045 MHz (TV), 10 MHz ~ 1200 MHz(Satellite)
Frquency Step 10 kHz (TV), 1 MHz (Satellite)
Resolution Bandwidth (-3
dB)
30 kHz, 100 kHz, 300 kHz, 1 MHz,
3 MHz (TV) 1 MHz, 3 MHz Auto Select (Satellite)
Level Measurement Range 10 dBμV ~ 120 dBμV (TV) 30 dBμV ~ 120 dBμV (Satellite)
Accuracy Of Measurements <1.5 dB
Measurement Detector Peak, sample, AVG (TV) , No Select for Satellite
Reference Level 30 dBμV ~ 120 dBμV
Markers 2 (TV) 1 (Satellite)
Analogue TV Measurement
Standards B/G, I, D/K, L/L´, M/N
Colour Standards PAL, SECAM, NTSC
Frequency Step 10 kHz
Hum Measurement > 50dB
C/N > 50dB
Level Measurement Range 30 dBμV ~ 120 dBμV
Accuracy Of Measurements < 1.5 dB
Level Resolution 0.1 dB
Digital CATV Measurement
Modulation Type 16/32/64/128/256 QAM ITU-T J.83 ANNEX A/B/C
Symbol Rate 4.0 MS/s ~ 7.0 MS/s
Power Level Range 30 dBμV ~ 110 dBμV
Level Resolution 0.1 dB
Power Level Accuarcy ±1.5 dB(C/N > 20 dB)
MER Measurement ~40 dB
MER Accuracy ±2.0 dB
BER 1E-3 ~ 1E-9
Constellation √
DVB-T/H Measurement
Modulation Type QPSK, 16 QAM, 64 QAM
Power Level Range 25 dBμV ~ 110 dBμV
Level Resolution 0.1 dB
Power Level Accuarcy ±1.5 dB (C/N >20 dB)
MER Measurement > 30 dB
MER Accuracy ±2.0 dB
CBER/VBER √
Constellation √
MER Versus Carriers √
Echo Pattern √
DVB-T2 Measurement
Modulation Type QPSK, 16 QAM, 64 QAM, 256QAM
Power Level Range 25 dBμV ~ 110dBμV
Level Resolution 0.1dB
Power Level Accuarcy ±1.5 dB(C/N >20 dB)
MER Measurement >30 dB
MER Accuracy ±2.0 dB
CBER/LBER √
Constellation √
Echo Pattern √
ATSC Measurement
Modulation Type 8 VSB
Power Level Range 25 dBμV ~ 110 dBμV
Level Resolution 0.1 dB
Power Level Accuarcy ±1.5 dB(C/N >20 dB)
MER Measurement >35 dB
MER Accuracy ±2.0 dB
BER √
Constellation √
DTMB Measurement
Carriers C=1, 3780
Power Level Range 25 dBμV ~ 110 dBμV
Level Resolution 0.1 dB
Power Level Accuarcy ±1.5 dB (C/N >20dB)
MER Measurement >28 dB
MER Accuracy ±2.0 dB
BER √
Specifications
Constellation √
Echo Pattern √
DVB-S/S2 Measurement
Modulation Type QPSK, 8PSK
Symbol Rate
2 - 45 MS/s (DVB-S)
1 - 45 MS/s (QPSK DVB-S2)
1 - 45 MS/s (8PSK DVB-S2)
Power Level Range 40 - 110 dBμV
Level Resolution 0.1 dB
Power Level Accuarcy ±1.5 dB (C/N>20dB)
MER Measurement > 25 dB
MER Accuracy ±2.0 dB
BER
DVB-S (CBER/VBER)
DVB-S2 (CBER/LBER)
Constellation √
Video/Audio Decoder
Video MPEG1/2/4, H.264
Video Resolution 1080i, 720p and 576i
Audio MPEG1/2/4, AAC
CAM Module EN50221 (DVB-CI) PCMCIA interface
TS-ASI Input And Output √
TS Record √
TS Analyzer
En 50083-9(DVB SPI, ASI)
DVB-ASI Interface 75 Ω BNC
DVB-ASI Clock 270 MHz
DVB-ASI Max Data Rate 0 to 72 Mbps
DVB-ASI Output Signal
Level
1.0 Vp-p nominal
DVB-ASI Return Response > 15dB
DVB-ASI Input Level 800 mV +/- 10%
Realtime Decoder
Display the real television pictures (through CA system).
Including program numbers, program names, provider
information, video & audio PIDs
TR101290 Monitor TR101 290 three levels real time monitor
Base Information
Count the PIDs percent according to the type of the streams.
Videos, Audios, PSI/SI, Null Packages
PID List Display all the PIDs in current stream
Program Information
The detail infos about a program if it isn’t be encrypted.
The video resolutions and audio compress rate.
PCR Monitor Calculate PCR interval and PCR accuracy
PSI/SI List
Display the PSI/SI infos by tree view. Including PAT,PMT,CAT,(
NIT,SDT,RST,TDT,EIT options)
Program Info EPG
PID Capture
Capture a specified PID by it’s type: Video, Audio, PSI(PAT,P
MT,NIT,TDT,RST,SDT,EIT) etc. And display the data in HEX
format
Transport Stream Record and
Replay <2 GB (udisk) for TS record and TS Replay
Interface
RF Input 75 Ω F
HDMI Output
USB 1 USB 2.0
LAN 1 10/100 M
DVB-CI 1 PCMCIA
TS-ASI Input/Output 2 75 Ω BNC
DC Supply Input 12 V / 5 A
GPS Input USB
General
Display 7 inches TFT LCD 800 × 480 pixels
AC/DC Adapter AC 100 - 240 V/50-60 Hz DC 12 V/5 A
Battery Li-ion, 7.4 V/13 Ah
Charge Time Around 5 Hours
Working Time >5 Hours
Remote Feeding 5/13/15/18/24 V, Max. 5 W
22 kHz Control Signals DiSEqC 1.2 and SaTCR
Dimension (W×H×L) 245 mm × 194 mm × 105mm
Weight Around 2.8 kg
Working Temperature -10 ~ +50 ℃
Storage Temperature -20 ~ +70 ℃
