DATA SHEET

W W W. D E L O C K . C O M

Description

Specification

© 2011 by Delock. All names and symbols mentioned here are property of the respective producer.

Printing errors, changes and errors excepted.

Images

PCI Express Card > 2x Power

Over eSATA 5V/12V

This PCI Express Card expands your PC by
two Power Over eSATA ports. This interface
enables you to connect not only Power Over
eSATA devices but also standard eSATA and
standard USB devices, like external enclosure,
card reader etc. The combination of eSATA
and USB in one port enables the power supply
via USB, so that you do not require any power
supply when using a 2½” Power Over eSATA
enclosure.

The internal 12V connector of the PCI Express
card provides you an external connection for
additional products e.g. 3,5“ HDD, which require
more than 5V. Therefor you can use optional
connecting cables by Delock.

• 2x external Power Over eSATA
• For Power Over eSATA devices, eSATA devices or USB devices
• Data transfer rate: USB 2.0 up to 480 Mbps
eSATA up to 3 Gbps
• PCI Express x1 Standard
• Supports PCI Express 1.1 specification
• Power supply: 5V, 12V
• Raid 0, 1, 5, 10
• Supports SATA Port-multiplier (multiple SATA devices on one
port)
• For Windows 2000/Server-2003/Server-2003-64/XP/XP-64/
Vista/Vista-64, Linux, MAC 10.4.x or later

System requirement
• Windows 2000/Server-2003/Server-2003-64/XP/XP-64/Vista/
Vista-64, Linux, MAC 10.4.x or later
• PC with a free PCI Express slot
• Mainboard with a free USB pinheader
• 12V power cable 3.5“

Package content
• PCI Express card
• USB cable
• Driver CD
• User manual

Package

• Blister

89233
4043619892334
Taiwan
84733020

Ref.
EAN

Country of origin

Customs tariff number
