Description
The Delock PCI Express card expands your PC by two external serial Ports. You
can connect devices like scanner, modem, mouse etc. to the card.
Specification
• Oxford chipset
• 2 x RS-232, DB9 serial port
• Data transfer rate up to 230.4 Kb/s
• Compatible with 16C950 UART
• FIFO: 128 byte
• PCI Express x1 standard
• Supports PCI Express 1.1 specification
System requirements
• Windows 2000/XP/Server-2003/Server-2003-64/Vista/Vista-64/7/7-64
• PC with one free PCI Express Slot
Package content*
• PCI Express card
• 2 x low profile bracket
• Driver CD
• User manual
*Make sure that the product package contains all items before operation. If any
item is missing or damaged, then please contact your dealer immediately.
Safety instructions:
• Protect the product against moisture
• Avoid anti-static electricity when installing the card
Hardware Installation
Note:
Follow the general instructions for installation of the card. If necessary, read the
manual of your computer, or ask a specialist for help.
1. Turn off your PC, and unplug the power cord.
2. Open the housing.
3. Remove the slot holder from the available PCI Express slot.
4. Insert the card straight and carefully into the free PCI Express slot, until it is
well seated.
