DATA SHEET

W W W. D E L O C K . C O M

Description

Specification

Printing errors, changes and errors excepted.

Images

PCI Card >

1x external Power Over eSATA 5V/12V

1x internal SATA

This PCI Express Card expands
your PC by one external Power Over
eSATA, as well as one internal SATA
port. This external interface enables
you to connect not only Power Over
eSATA devices but also standard
eSATA and standard USB devices, like
external enclosure, card reader etc.
The combination of eSATA and USB in
one port enables the power supply via
USB, so that you do not require any
power supply when using a 2.5 Power
Over eSATA enclosure.

The internal 12V connector of the PCI
Express card provides you an external
connection for additional products
e.g. 3.5 HDD, which require more than
5V. Therefor you can use optional
connecting cables by Delock.

• External: 1x Power Over eSATA
• For Power Over eSATA devices, 
eSATA devices or USB devices
• Internal: 1x SATA, for SATA devices
• Data transfer rate: 

USB 2.0 up to 480 Mbps

SATA up to 1.5 Gbps

• 32-Bit PCI Standard 2.2
• Power supply for the eSATAp port: 5V, 12V

System requirement
• Windows 2000/XP/Vista/7
• PC with a free PCI slot
• Mainboard with a free USB pinheader

Package content

• PCI card
• USB cable, power cable
• Driver CD
• User manual

Package

• Blister

89238

4043619892389

Taiwan
84733020

Ref.

EAN

Country of origin

Customs tariff number
