DeLOCK 88539 - Manual

DATA SHEET W W W. D E L O C K . C O M
Description
Specification
© 2011 by Delock. All names and symbols mentioned here are property of the respective producer.
Printing errors, changes and errors excepted.
Images
Ref.
EAN
Country of origin
Customs tariff number
Network
USB 2.0 WLAN b/g/n
Nano Stick 150 Mb/s
Connect the Wireless LAN USB stick
to your computer in order to set up
a wireless internet connection. The
WLAN stick can be connected to any
AccessPoint (HotSpot) or WLAN-router
in a 2.4 GHz Band. Furthermore it
enables an adhoc connection to another
notebook or PC.
• Realtek chipset
• 1T1R mode with 150 Mb/s PHY rate
• Frequency Band 2.4 GHz ISM Band
• RF output power: 16~18 dBm (CCK), 13~15 dBm (OFDM)
• Compatible to IEEE 802.11n and IEEE 802.11 b/g
• Security WEP 64bit/128bit WPA, WPA2
• Power supply: 5 V
• Power consumption: TX mode: 130 mA
RX mode: 90 mA
standby: 82 mA
• Dimension (LxWxH): 19,2 mm x 15 mm x 7,4 mm
System requirements
• Windows XP/XP-64/Vista/Vista-64/7/7-64, Mac ex OS 10.4,
Linux ex Kernel 2.6
• PC or Notebook with a USB Port
Package content
• WLAN USB stick
• Driver CD
• User manual
Package
• Blister
88539
4043619885398
Taiwan
84718000
