DeLOCK 89294 User Manual
DeLOCK Hardware
DATA SHEET
W W W. D E L O C K . C O M
Description
Specification
© 2011 by Delock. All names and symbols mentioned here are property of the respective producer.
Printing errors, changes and errors excepted.
Images
Ref.
EAN
Country of origin
Customs tariff number
PCI Express Card > Mini PCI
Express + 3 RP-SMA Ports
The Delock PCI Express card by Delock
enables you to use a Mini PCI Express
card in a PCI Express slot. Due to its
three pre-punched RP-SMA sockets the
card is most suitable for radio modules.
• PCI Express card to Mini PCI Express
• PCI Express x1
• Installation up to 3 SMA antennas
• Voltage: 3.3 V / 5 V
• 3 x connection cable IPEX to RP-SMA
• 4 x fixing holes for half-size and full-size modules
• Metal cover to protect the module
• LED indicator
• OS independent, no driver installation required
System requirements
• PC with one free PCI Express slot
Package content
• PCI Express card
• 3 x SMA antennas
• Spacers
Package
• White box
89294
4043619892945
China
84733020
