DATA SHEET

W W W. D E L O C K . C O M

Description

Specification

© 2009 by Delock. All names and symbols mentioned here are property of the respective producer.

Printing errors, changes and errors excepted.

Images

Ref.

EAN

Network

USB 2.0 WLAN_N
Stick 300 Mbps

Connect the Wireless Lan USB stick
to your computer, in order to achieve
a wireless internet connection. The
WLAN stick can be connected to any
Accesspoint (HotSpot) or WLAN-router
in a 2.4 GHz Band.

• Realtek chipset
• USB 2.0 specification
• Data transfer rate up to 300 Mbps
• With WPS button
• Power consumption: 5V/380mA
• Frequency Band 2.4GHz ISM Band
• Operation range: indoor up to 100 meter, outdoor up to 280 m
• RF output power: <14dBm at 11n, <17dBm at 11b, <14dBm at 11g
• Compatible to IEEE 802.11n and IEEE 802.11 b/g, 802.3, 802.3u
• Security WEP 64bit/128bit, TKIP, AES, WPA, WPA2
• Dimension (LxWxH): 52 mm x 25 mm x 10 mm

System requirements
• Windows XP/XP-64/Vista/Vista-64/7, Linux ex Kernel 2.6,
Mac ex OS 10.4
• PC or Notebook with a USB Port

Package content
• WLAN USB stick
• Driver CD
• User manual

Package
• Blister

88530

4043619885305

WPS button
