DATA SHEET

W W W. D E L O C K . C O M

Description

Specification

© 2010 by Delock. All names and symbols mentioned here are property of the respective producer.

Printing errors, changes and errors excepted.

Images

Ref.

EAN

Country of origin

Customs tariff number

Cable USB 2.0-A female to

pin header

This USB cable by Delock is designed
to connect a device with a USB
interface to an internal pin header of the
mainboard.

• Connector: USB 2.0-A female 5pin > pin header 5pin
• Pin header: red=VCC(+5V)

green=Data+(D+)

white=Data-(D-)

black=GND (Ground)

• For internal connection
• Cable length: ca. 40 cm

Package content
• USB 2.0 cable to pin header

Package
• Delock poly bag

82433

4043619824335

China

85444290
