DeLOCK 87514 User Manual

Delock wlan router 11n

Delock WLAN Router 11n

Description

This Delock Wireless Lan Router provides a wireless
Internet access at a maximum speed of 150 Mb/s. There are
as well four network ports to integrate your wired
computers into your local network.

Specification

• Realtek chipset
• 1 x WAN 10/100 BaseT connector RJ 45
• 4 x LAN 10/100 BaseT connector RJ 45
• 1 x 2dBi external antenna (1T1R)
• Buttons: WPS, reset
• Data transfer rate up to 150 Mb/s
• Frequency Band 2.4 GHz ISM Band
• Operation range: indoor up to 100 meter, outdoor up to 280 meter
• Compatible to IEEE 802.11n and IEEE 802.11 b/g, 802.3, 802.3u
• Security WEP 64 bit / 128 bit, TKIP, AES, WPA, WPA2
• Electrical power: 3 W
• Dimension (LxWxH): 108 mm x 68 mm x 24 mm

Item No. 87514

EAN

4043619875146

Country of origin

CHINA

System requirements

• Modem / DSL connection

Package content

• WLAN Router
• Antenna
• 1 x RJ 45 cable 1.5 m
• Power supply
• CD-ROM
• User manual

Package

• Retail Box
