DeLOCK 87592 User Manual

Delock switch hdmi 3in + mhl 1in > 1out

Delock Switch HDMI 3in + MHL 1in > 1out

Description

This Delock HDMI switch enables you to connect up to
three HDMI devices as source through each HDMI input
port. Furthermore this switch provides a MHL input port for
connection of a smartphone with MHL interface, which can
be used as input source. You can select the input source
either at a push of a button or by using the included remote
control.

Specification

• Connector:
Input:
3 x HDMI-A 19 pin female
1 x MHL female
Output:
1 x HDMI-A 19 pin female
Power:
1 x DC 5 V / 2 A
• High Speed HDMI specification
• Resolution up to Full-HD 1080p
• HDMI / MHL port switch by push button or remote control
• Supports 12 bit deep colour per channel
• HDCP support
• Supports a bandwith of up to 250 MHz / 2.5 Gb/s per channel
• Power consumption: max. 5 W
• LED indicator for power, active input source
• Dimension: (LxWxH): 155 mm x 70 mm x 25 mm

Item No. 87592

EAN

4043619875924

Country of origin

China

Package content

• HDMI + MHL Switch
• Power supply, remote control, MHL
connecting cable 1 m
• User manual

Package

• Box
