DeLOCK 88749 User Manual
DeLOCK Hardware
Delock LTE Antenna SMA omnidirectional black outdoor
Description
This LTE antenna can be installed indoors or outdoors and
is suitable for all four bands of LTE. The antenna is fully
compatible with GSM / UMTS / WLAN 2.4 GHz, ZigBee
and Bluetooth.
Specification
• LTE Band: 1, 3, 7, 20
• GSM/ UMTS
• WLAN 2.4 GHz
• ZigBee
• Bluetooth
• Frequenzy range: 790 - 870 MHz, 1710 - 2690 Mhz
• Gain: 2 dBi
• Polarisation: linear vertical
• Impedanz: 50 Ohm
• VSWR:
2.0 max. @ 750~960 MHz/ 1710~2170 MHz
3.0 max. @ 2400~2700 MHz
• Dimension:
height: 48 mm
diameter: 50 mm
• Screw mounting 12 mm central hole
• Cable length: 3 m
• Cable type: RG-174
• Connector: SMA plug
• Operating temperature: -10 °C ~ 55 °C
• ABS UV resistant
• IP 67
Item No. 88749
EAN
4043619887491
Country of origin
China
© 2013 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes and errors excepted.
www.delock.com
1
