Delock PCI Card > 8 x Serial RS-232 High Speed 921K

Description

The Delock PCI card expands your system by eight High
Speed RS-232 ports. Use this card for applications like data
logging, machine control systems, automation, development
or communication. By the extensive surge protection and
the wide temperature range this card can be used in the
industrial area.

Specification

• Chipset: Systembase SB16C1058PCI
• Connector:
external:
1 x VHDCI 68 pin female
connecting cable: VHDCI 68 pin male > 8 x Serial RS-232
Sub-D 9 pin male
internal:
1 x PCI
• Baud rate: up to 921.6 Kb/s
• Compatible to 16C550 UART
• FIFO 256 Byte
• Data bit: 5, 6, 7, 8
• Stop bit: 1, 1.5, 2
• Parity: None, Even, Odd, Space, Mark
• Flow Control: RTS / CTS, XON / XOFF
• Operating temperature: -30 °C ~ +75 °C
• Storage temperature: -40 °C ~ +85 °C
• Ambient relative humidity max. 95 % (non-condensing)
• 15 kV ESD protection for all signals
• Bus: universal 32/64 Bit 3.3/5 V PCI version 2.1, 2.2, 2.3 and PCI-X
• I/O address and IRQ assigned by the system

Item No. 89329

EAN

4043619893294

Country of origin

Taiwan, Republic of

China
