DeLOCK 87619 User Manual

Delock hdmi 3 - 1 switch bidirectional

Delock HDMI 3 - 1 Switch bidirectional

Description

This HDMI switch by Delock is a manually bidirectional
switch for connecting different HDMI devices. This switch
offers two different application.

1. You can connect up to three HDMI devices to one

monitor, TV or beamer etc. with HDMI input port.
By using the button you can select which device
should display the signal.

2. You can connect one HDMI device to up to three

displays and select the monitor which should display
the signal by using the button. (Simultaneous output
to multiple screens is not possible)

Specification

• Connector:
Function 1
Input: 3 x HDMI-A 19 pin female
Output: 1 x HDMI-A 19 pin male
Function 2
Input: 1 x HDMI-A 19 pin male
Output: 3 x HDMI-A 19 pin female
• High Speed HDMI
• Resolution up to Full-HD 1080p
• HDMI port selection by button
• LED indicators for active HDMI port
• Supports VGA, SVGA, XGA, UXGA mode
• No external power supply needed
• HDCP pass through
• Length incl. connector: ca. 60 cm
• Plug & Play

Item No. 87619

EAN

4043619876198

Country of origin

China

Package content

• HDMI bidirectional switch
• User manual

Package

• Box
