DeLOCK 88395 User Manual
DeLOCK Hardware
Delock WLAN 802.11 a/b/g/n antenna RP-SMA 2 dBi omnidirectional joint
Description
This WLAN antenna can be connected to a RP-SMA port,
in order to receive or send signals.
Specification
• RP-SMA screw interface
• With flexible joint, rotatable
• Frequency range: 2.4000 ~ 2.4835 GHz,
5.1500 ~ 5.7250 GHz
• GAIN: 1.5 dBi @ 2.5 GHz
2.1 dBi @ 5.7 GHz
• Impedance: 50 Ohm
• VSWR: 2.0 max.
• Operating temperature: -20 °C ~ 65 °C
• Length with flexible joint 108 mm, without flexible joint 82.50 mm
• Ø: 7.8 mm (Ø peak) x 10 mm (Ø SMA)
Item No. 88395
EAN
4043619883950
Country of origin
Taiwan, Republic of
China
Package content
• WLAN antenna RP-SMA with flexible
joint
Package
• Poly bag
Images
© 2013 by Delock. All names and symbols mentioned here are property of the respective producer. Printing errors, changes and errors excepted.
www.delock.com
1
