Delock LTE band 20/1/3/7 antenna N jack 8 ~ 9 dBi directional white
outdoor
Description
This LTE antenna can be installed indoors or outdoors and
take advantage of all four bands for LTE. She is completely
compatible to UMTS / GSM / Bluetooth / WLAN 2.4 GHz.
Specification
• LTE Band: 20, 1, 3, 7
• Frequency range: 790 - 870 MHz, 1710 - 2690 Mhz
• GSM/UMTS
• WLAN IEEE 802.11 b/g/n 2.40 ~ 2.50 GHz
• Bluetooth
• ZigBee
• Gain: 8 ~ 9 dBi
• Polarisation vertical
• Impedance: 50 Ohm
- VSWR: 2,0:1
- N jack
- Dimension: 295 x 205 x 65 mm
- Cable length: 5 m
- Cable typ: RG-58
- Cable attenuation: 0.50 dB per meter @ 800 MHz
- Operation temperature. -40°C ~ 60°C
- ABS UV resitant
- Including pole mounting kit
Item No. 88808
EAN
4043619888085
Country of origin
China
Package content
• LTE antenna
Package
• Poly bag
