Delock LTE antenna SMA 1 ~ 4 dBi omnidirectional with flexible joint
black

Description

This GSM/UMTS/LTE antenna can be connected to your
GSM/UMTS/LTE device with SMA connector in order to
receive or to send a signal.

Specification

• SMA male screw interface
• With flexible joint, rotatable
• Frequency range: 791 ~ 960 MHz, 1710 ~ 2170 MHz, 2570 ~ 2620 MHz
• Peak gain: 1 ~ 3,5 dBi, 2 ~ 4 dBi, 3 ~ 4 dBi
• LTE band 1/2/3/4/7/9/10/13/14/17/20/25
• GSM1800/UMTS
• VSWR: 4.0 : 1 max.
• Polarization: linear, vertical
• Impedance: 50 Ohm
• ABS UV resistant
• Operating temperature: -10 °C ~o 55 °C
• Dimension: with flexible joint 163.10 mm,
without flexible joint 137.00 mm,
• Ø: 19.60 mm (top)
13,50 mm (base)

Item No. 88451

EAN

4043619884513

Country of origin

Taiwan, Republic of

China

Package content

• Antenna

Package

• Poly bag
