Delock LTE MIMO band 1/3/7/20 antenna SMA 2 ~ 4 dBi omnidirectional
gray outdoor
Description
This LTE MIMO antenna can be installed indoors or
outdoors and take advantage of all four bands for
LTE. She is completely compatible to UMTS / GSM /
Bluetooth / WLAN 2.4 GHz.
Specification
• LTE Band: 20, 1, 3, 7
• Frequency range: 790 - 870 MHz, 1710 - 2690 Mhz
• Gain: 2 dBi, 4 dBi
• UMTS/GSM/Bluetooth/WLAN 2,4 GHz
• Polarisation linear vertical
• Impedance: 50 Ohm
• VSWR: 2.5:1
• Connector: 2x SMA plug
• Dimension: 239.4 x 176 x 35 mm
• Cable length: 2x 5 m
• Cable connectors: SMA plug
• Cable typ: CFD-200
• Cable attenuation: 0.55 dB per meter @ 2.4 GHz
• Operating temperature: -10 °C ~ 55 °C
• ABS UV resistant
• IP 55
• Including wall/pole mounting kit
Item No. 88476
EAN
4043619884766
Country of origin
China
Package content
• LTE MIMO antenna
• 2 low loss CFD200 SMA cable
• wall/pole mounting kit
Package
• White Box
