Delock Converter RS-232 > RS-232 with 3 kV Isolation
Description
The Delock RS-232 converter separates the electrical
connection between Host-PC and USB device. The galvanic
isolation avoids the disturbing noises in the audio field and
inexact measuring results in the laboratory field.
Specification
• Connector:
Host: 1 x Sub-D 9 pin Serial RS-232 female
Device: 1 x Sub-D 9 pin Serial RS-232 male
1 x DC female port for 1.3 x 3.5 mm
• Data transfer rate up to 1 Mb/s
• LED indicators for status TX / RX and power supply
• 3 kV optical isolation
• ± 15 kV ESD protection for all signal pins
• Power consumption: 52 mA / 1248 mW
• Power supply via external provided power supply or pin 9 of
the serial interface
• Operating temperature: - 30° ~ 75° C
• Storage temperature: - 40° ~ 85° C
• Relative humidity: 5 ~ 95 % (not condensing)
• Housing: plastic
• Dimension (LxWxH): ca. 88 x 54 x 22 mm
• OS independent, no driver installation required
Item No. 62500
EAN 4043619625000
Country of origin Taiwan, Republic of
China
System requirements
• Device with one free RS-232 interface
Package content
• Converter
• Power supply 12 V / 1 A
• Mounting set for DIN rail
• User manual
Package
• Box
