Delock Converter USB 2.0 > Serial RS-422/485 with 3 kV Isolation

Description

The Delock USB to serial converter enables you to connect
a serial device to a free USB port. This USB converter
separates the electrical connection between Host-PC and
USB device. The galvanic isolation avoids the disturbing
noises in the audio field and inexact measuring results in the
laboratory field. The compact device supports the USB 2.0
specification with Low- and Full-Speed.

Specification

• Connector:
Host: 1 x Mini USB 2.0 B female
Device: 1 x RS-422/485 Terminal Block 5 pin
• Data transfer rate up to 1 Mb/s
• 1 x DIP switch: RS-422/485 set operating mode
• LED indicators for status TX / RX
• 3 kV optical isolation
• ± 15 kV ESD protection for all signal pins
• Power consumption: 54 mA / 270 mW
• Power supply via USB (Bus-Powered)
• Operating temperature: - 30° ~ 75° C
• Storage temperature: - 40° ~ 85° C
• Relative humidity: 5 ~ 95 % (not condensing)
• Housing: plastic
• Dimension (LxWxH): ca. 101 x 42 x 22 mm

Item No. 62501

EAN

4043619625017

Country of origin

Taiwan, Republic of

China

System requirements

• Windows XP/XP-64/Vista/Vista-64/7/7-64/8/8-64, Mac OS 10.5,
Linux Kernel 2.6
• PC or notebook with one free USB port

Package content

• Converter
• USB 2.0 cable, length: ca. 1 m
• Mounting set for DIN rail
• Driver CD
• User manual

Package

• Box
