DeLOCK 62487 User Manual

Delock converter usb > usb with 5 kv isolation

Delock Converter USB > USB with 5 KV Isolation

Description

The Delock USB converter separates the electrical
connection between Host-PC and USB device. The galvanic
isolation avoids the disturbing noises in the audio field and
inexact measuring results in the laboratory field. The
compact device supports the USB 2.0 specification with
Low- and Full-Speed.

Specification

• Connector:
Host: 1 x Mini USB 2.0 female
1 x DC power connector female
Device: 1 x USB 2.0 type A female
• Data transfer rate up to Full-Speed 12 Mb/s
• Full-Speed or Low-Speed USB adjustable by DIP switch
• LED indicators for status
• 5 kV optical isolation
• Operating temperature: - 30° ~ 75° C
• Storage temperature: - 40° ~ 85° C
• Relative humidity: 5 ~ 95 % (not condensing)
• Housing: plastic
• Dimension (LxWxH): ca. 88 x 42 x 22 mm
• OS independent, no driver installation required

Power supply specification

• Wall power supply
• Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.5 A
• Output: 12 V / 1 A
• Ground outside, plus inside
• Dimensions:
inside: ø ca. 2.1 mm
outside: ø ca. 5.5 mm
length: ca. 9.5 mm

Item No. 62487

EAN

4043619624874

Country of origin

Taiwan, Republic of

China
