DeLOCK 61664 - Manual

DATA SHEET WWW.DELOCK.COM
Description
Specification
Ref.
EAN
© 2009 by Delock. All names and symbols mentioned here are property of the respective producer.
Printing errors, changes and errors excepted.
Images
Converter IDE 40pin
> SATA 2x HDD
This converter by Delock enables you
to connect 2 SATA HDDs via 40pin IDE
interface. The converter can be easily plug
onto the 40pin male port of your mainboard
and does not require any driver installation.
Furthermore the SATA HDDs can be set to
Master and Slave.
Note: 2 SATA HDDs need to be connected!
-When using the 2 SATA HDD in Slave-mode,
please arrange the setting in the Bios.
-When using the 2 SATA HDD in Master-mode,
the jumper needs to be set accordingly.
• Connector: IDE 40pin female to SATA 7pin
• Supports ATA 100/133
• SATA HDD setting for Master and Slave
• No driver required
System requirement
• Mainboard with 40pin IDE male connector
Package
• Delock poly bag
61664
4043619616640
