DATA SHEET

WWW.DELOCK.COM

Description

Specification

© 2009 by Delock. All names and symbols mentioned here are property of the respective producer.

Printing errors, changes and errors excepted.

Images

Ref.
EAN

Slot bracket

eSATAp 5V/12V + USB 2.0

This slot bracket enables you to lead out

the internal ports, in order to connect

devices to the externally available

eSATAp and USB ports. The eSATAp

port provides a voltage supply of 5V and

12V, thus you can connect also 2,5” and

3,5” HDDs to this interface, by using

special Delock products, like eSATAp

cable or docking stations.

• Slot bracket for installation into a PC slot
• Internal: 1x 9-Pin USB, 1x SATA, 1x Power 4-Pin
• External: 1 x Power Over eSATA 5V/12V (eSATAp), 1 x USB 2.0
• Plug & Play
• OS independent, no driver installation required

System requirements

• PC with one free Slot

Package content

• Slot bracket
• Low Profile Bracket
• SATA cable
• USB cable
• Power cable
• User manual

Verpackung

• Retail Box

61824
4043619618248
