Familiarise yourself with the functions of the device before actually using
it.
•
All modifications of the device are forbidden for safety reasons.
•
Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol
or solvents.
•
Only use the device for its intended purpose. Using the device in an
unauthorised way will void the warranty.
•
Damage caused by disregard of certain guidelines in this manual is not
covered by the warranty and the dealer will not accept responsibility for
any ensuing defects or problems.
•
Note that damage caused by user modifications to the device is not
covered by the warranty.
4. Overview
Refer to the illustration on page 1 of this manual.
A IR bender receiver/transmitter D PSU input connection
B IR probes output connection E IR receiver extension
C IR receiver extension input connection F IR probes
5. Installation/Operation
Refer to the illustration on pages 1 and 2 of this manual.
Application [1]: Use with IR bender only
•
Insert the plug of the IR probes [F] into the IR probes output connection [B]
at the back of the IR bender [A].
•
Install the IR bender flat on a horizontal surface within sight and reach of
your remote control (± 6m in ideal circumstances).
•
Lead the IR probes inside the cabinet and to the A/V equipment in such
way that a LED can be stuck onto the IR eye of each A/V apparatus. Test
the position of each LED first before sticking as this should be done
carefully and precisely.
•
Insert the plug of the PSU into the PSU input connection [D] at the back of
the IR bender. Only use the supplied PSU. Connect the PSU to the mains.
•
Use your remote control and point towards the IR bender within an angle
of ± 15° in all directions.
Application [2]: Use with IR receiver extension
•
Insert the plug of the IR probes [F] into the IR probes output connection [B]
at the back of the IR bender [A].
•
Insert the plug of the IR receiver extension [E] into the IR receiver
extension input connection [C].
•
Install the IR bender flat on a horizontal surface within sight and reach of
your remote control (± 6m in ideal circumstances) or inside the cabinet.
•
Stick the IR receiver extension preferably onto a vertical surface, next the
