DVM1500
V. 03 – 04/11/2013 13 ©Velleman nv
overvoltage category 1000 V CAT II and 600 V CAT III
pollution degree
2
operating temperature 0 °C (32 °F) – 40 °C (122 °F) (< 80 % RH, < 10 °C)
storage temperature
-10 °C (14 °F) – 60 °C (140 °F) (< 70 % RH, remove
batteries!)
temperature
coefficient 0.1x/°C (< 18 °C or > 28 °C)
max. voltage between
terminals and earth 750 Vac rms or 1000 Vdc
fuse protection μA and mA, F500mA/250V, 5 x 20 mm (10A range not
protected)
sample rate 3x/s
display 3 ¾ digits LCD with automatic indication of functions
and symbols
overrange indication yes (“OL”)
low battery indication yes ( )
polarity indication “–” displayed automatically
data hold yes
backlight yes
auto power off yes, after 15 min. Buzzer sounds after 14 min as a
warning.
power supply 3 x 1.5 V AAA batteries
dimensions 85 x 180 x 45 mm
weight (with battery) ± 280 g (incl. holster)
accessories
manual, test probes, batteries, K-type thermocouple
Non-Contact AC Voltage Detector
Sensitivity
Frequency Distance
> 50 V 50 Hz < 150 mm
DC Voltage
Range
Resolution Accuracy
400 mV 0.1 mV
± (0.8 % of reading + 3 digits)
4 V 1 mV
40 V 10 mV
400 V 100 mV
1000 V 1 V ± (1.0 % of reading + 3 digits)
Input impedance: 10 MΩ
Max. input voltage: 1000 Vdc
AC Voltage
Range
Resolution Accuracy
4 V 1 mV
± (1.0 % of reading + 3 digits) 40 V 10 mV
400 V 100 mV
