3. Continue deleting desired codes.
4. Exit the programming mode by pressing .
7. Technical Specifications
•
Operation Voltage
12V-24V AC/DC, no jumper required for voltage selection
•
Operation Modes
a)
Single user mode, auto or manual code entry
b) Multi-user mode: 100 user codes for output 1 (user number 00-99), auto or manual code entry
10 user codes for output 2 (user number 0-9), auto or manual code entry
10 user codes for output 3 (user number 0-9), auto or manual code entry
•
User Code Combinations
a)
Single user mode: 10 000
b) Multi-user mode: 111 110 000
•
Input Sensing Terminals
a)
Egress input: N.O. referring to (-) ground
b) Door position sensor input: N.C. referring to (-) ground
c) Relay 1 stop control: N.O. referring to (-) ground
•
Relay Output Contacts
OUTPUT 1: N.C. and N.O. dry contacts, 5A / 30VDC max. rating
OUTPUT 2: N.C. and N.O. dry contacts, 1A / 30VDC max. rating
OUTPUT 3: NPN open collector, 100mA sink / 24VDC max.
•
Tamper Switch Contact
N.C. dry contact, 50mA max.
•
Duress, Interlock and Key-Active Output Rating
NPN open collector switches to ground when active, 24DC / 100mA sink
•
Auto Refreshing Time during Code Entry
a)
Each digit max. entry time limit: 10 seconds
b) Each code max. entry time limit: 30 seconds
•
Dimensions
117 x 74 x 48mm
•
Weight
180g
8. Application Examples
1. Basic wirings of a stand-alone door
lock with inhibit authorization code
and indication (fig. 2)
•
Connect the 1N4004 as close as
possible to the lock in parallel with
