MONCOLHA3

(07/11/2008)

Velleman

4. Features

• 2 x video/camera inputs

• OSD (on-screen display)

• automatic trigger function for reverse camera

• comes with: remote control, cables and mounting stand

5. Overview

Refer to the illustration on page 2 of this manual.

A sun shade

H IR transmitter

B IR sensor

I ON/OFF button

C ON/OFF button

J video select button

D video select button

K menu button

E mode select button

L increase button

F status indication

M mode select button

G mounting bracket

N decrease button

6. Installation

Refer to the drawing on page 2 of this manual.

1 monitor connector plug

5 ground cable (black)

2 fuse box

6 video in 1

3 reverse cable (green)

7 video in 2

4 +12VDC power cable (red)

The car connection should be carried out by a qualified person only.
• Choose a mounting location, depending on the purpose of the monitor.

When used to connect backing-up or parking camera(s), the driver should

have a clear view of the display. For all other purposes make sure the driver
is not distracted by images and/or sound from the system.

• Mount the mounting bracket [G] and attach the monitor to the bracket with

the 4 included screws.

• Connect the monitor connector plug [1] with the jack of the monitor.

• Connect a camera/video/DVD… (not incl.) to a video input [6][7].

• Make sure the engine is switched off.

• Connect the red +12VDC power cable [4] to the +12VDC power system

of the car. Make sure there is no power on the connection wire (remove

fuse).

• Connect the black ground cable to the car ground.

• The monitor can switch on/over to AV2 automatically when reverse gear

is selected. To enable this functionality, connect the green reverse cable
