DCM267N
00 (04/11/2008)
6
Velleman
®
• Insert the side of the temperature probe adapter marked with “+” in the
"V Ω °C/°F" jack [10] and the other side (“-”) in the "COM" jack [9].
• Hold the probe head to the device under test for ±30s and read the value
in the LCD display.
• Do not change the rotary function switch when the thermocouple is
connected to the meter.
7. Battery
• When the low battery indication appears, replace the internal battery.
• Always disconnect test leads when replacing the battery. Do not us the
device without batteries installed.
• The battery cover is located on the back of the device and is closed with
one screw. Remove the screw and open the battery compartment.
• Remove the battery and insert a new 9V battery following the polarity as
indicated in the battery holder. Only use a new battery of the same type
and specifications.
• Reinstall the cover and secure it with the screw.
•
Remove the battery when the device will not be used for a long time to avoid
leakage.
•
Do not recharge non-rechargeable batteries and do not throw in fire as they
may explode.
WARNING: handle batteries with care, observe warnings on
battery casing. Dispose of batteries in accordance with local
regulations.
Keep batteries away from children.
8. Technical Specification
DC voltage
0.4/4/40/400/600V
basic accuracy
±(1.5% of rdg + 3 digits) / ±(0.8% of rdg + 3
digits) for 0.4V range / ±(2.0% of rdg + 3 digits)
for 600V range
input impedance
7.8Mohm
maximum input
600V
AC voltage
0.4/4/40/400/600V
basic accuracy
±(1.8% of rdg + 5 digits) / ±(0.8% of rdg + 20
digits) for 0.4V range / ±(2.5% of rdg + 5 digits)
for 600V range
input impedance
7.8Mohm
frequency range
50-60Hz
maximum input
600V
AC current
40/400/1000A (max. line voltage 240V)
basic accuracy
±(2.5% of rdg + 10 digits) for 40A range / ±(2.5%
of rdg + 5 digits) for 400A range / ±(3.0% of rdg
+ 4 digits) for 1000A range
resistance 400/4K/40K/400K/4M/40M
basic accuracy
±(1.0% of rdg + 4 digits) for 400ohm range /
±(1.5% of rdg + 2 digits) for 4K~400K range /
±(2.5% of rdg + 3 digits) for 4M range / ±(3.5%
of rdg + 5 digits) for 40M range
overload protection 15s max. 250V (all ranges)
