DVM601
22/08/2013 ©2008 Velleman ® Components nv 4
unauthorised way will void the warranty.
• Caution: risk of electroshock when measuring voltages > 36VDC, 25VAC,
currents > 10mA, AC power lines with inductance load and AC power lines
with fluctuating power.
• Only use the included test leads. When damaged, replace them with test
leads of the same type and with the same specifications.
• Always verify that all connections are reliable and safe.
• Before measuring, always check the selected range.
• Avoid body contact with ground potential (e.g. metallic terminals, output
sockets, lead clamp…) while measuring. Make sure to be electrically
insulated from ground during measurement.
• Always use the device within its specified range.
• Calibration and repair must be performed by a qualified technician. Refer to
your local dealer.
• Never attempt to measure voltages when connected to the current
terminal.
4. Features
• CAT. III - 1000V, CAT. IV - 600V
• measure: sound-level, light, humidity, temperature, DC & AC
voltage, DC & AC current, frequency, capacitance, resistance, diode
& continuity test, live wire test ...
• low-battery indication
• auto ranging (except ranges Vac 400mV, Iac 10A and Idc 10A)
• built-in non-contact AC voltage detector (50-1000VAC)
5. Overview and use
Refer to the illustrations on page 2 of this manual.
1 humidity & temperature sensor
measure room temperature and relative humidity
2 LCD
3 4/5 digits LCD display
3 function rotary switch
select function
4 V/Hz%/Ω/Cap/ °C input
input jack for V, Hz%, Ω, Cap or °C measurement (red lead)
5 COM input
common input jack (black lead)
6 µA/mA input
input jack for µA or mA range measurement (red lead)
7 10A input
input jack for 10A range measurement (red lead)
8 microphone
condenser microphone for noise measurement
