MONCOLHA5P VELLEMAN
2
e) The POWER button activates/deactivates the LCD monitor. It is not necessary to disconnect the 12VDC power
adapter.
4. Wiring Diagram = Bedrading = Câblage
Note that the 12VDC adapter is optional.
5. Specifications / Specificaties / Spécifications
ENGLISH NEDERLANDS FRANCAIS SPECS
Display Display Afficheur TFT colour LCD
Pixels Pixels Pixels 224640
Screen Size Schermgrootte Dimensions de l'écran 5.6" = 14cm (diag.)
Dot Pitch Tussenafstand pixels Dot pitch 0.12 (H) x 0.36 (V) mm
System Systeem Système PAL/NTSC
Input Signal Ingangssignaal Signal d"entrée 1.0Vp-p composite video signal, 75 Ω
Power Source Voedingsbron Source d'alimentation 12VDC ± 10%
Operating Temperature Werktemperatuur Temp. d'opération 0°C → +50°C
Storage Temperature Opslagtemperatuur Température de stockage -20°C → +80°C
Power Consumption Verbruik Consommation max. 7.5W
Dimensions (W x H x D) Afmetingen (B x H x D) Dimensions (La x H x P) 160 x 133 x 31.4 (mm)
Weight Gewicht Poids 465g ± 5g
