Search
• To search an event, press the LIST button on the front panel.
The system displays an overview of recorded file types.
• You can search the recordings by file type. Available types are ALARM, MANUAL, MOTION, SYSTEM and
FULL LIST.
• Select a list and recording from this list.
• Press ENTER to start play-back.
Note: the recorded files can also be searched via the included Video Viewer software.
10. Technical specifications
DVR
video format PAL
video compression H.264
video input 4 channels, composite video signal 1 Vpp / 75 ohms BNC
video output composite video signal 1 Vpp / 75 ohms BNC + VGA
video loop out -
maximum recording rate (PAL) frame/D1: 704 x 576 pixels with 100 IPS (PAL)
image quality setting super best - best - high - normal
hard disk storage built-in SATA type, supports 1 x HDD, supports HDD capacity over 2 TB
(HDD not incl.)
HDD quick cleaning quick cleanup the "index system" of the recorded files. 1 TB under 2
seconds
recording mode manual / timer / motion / network / alarm controlled
refresh rate 100 IPS for PAL
multiplex operation live display, record, playback, backup and network
audio I/O 4 x audio in, 1 x audio out (mono)
motion detection area 16 x 12 grids per channel
motion detection sensitivity high - normal - low
pre-alarm recording 8 MB
backup device USB 2.0 flash drive (for backup and firmware updates)
Ethernet 10/100 Base-T, supports remote control and LiveView via Ethernet
network connection supports TCP/IP, PPPoE, DHCP and DDNS function
mobile surveillance Smartphones: EagleEyes software:
- push video: on iPad, iPod Touch, iPhone and Android phone
- remote login via all smartphone platforms (Apple, Android, Blackberry,
Nokia Symbian and Window Mobile)
Computer:
- video viewer software on Windows and Mac:
- web browser: Internet Explorer, Firefox, Google Chrome and Safari via
Java, QuickTime or VLC plug-in
IR remote control remote control DVR and PTZ (DVRRC4 incl.)
PTZ control yes (via RS-485)
alarm I/O 4 in / 1 out
digital zoom 2 x (live & playback)
key lock yes
video loss detection yes
camera title up to 6 characters
video adjustments hue / colour / contrast / brightness
date display format YY/MM/DD, DD/MM/YY, MM/DD/YY, and off
power source 19 Vdc
power consumption < 40 W
daylight saving yes
operating temperature 10 °C ~ 40 °C (50 °F ~ 104 °F)
