CFAN0230 - CFAN0245
30.11.2010 ©Velleman nv 4
5. Overview
Refer to the illustrations on page 2 of this manual.
1 front grille 5 motor assembly
2 fan blade 6 control buttons
3 rear grille 7 power cord
4 base
6. Operating instructions
Refer to the illustrations on page 2 of this manual.
Note: Never use the fan without the safety grill in place.
•
Carefully unpack the fan and remove all shipping materials before operating.
• Place the fan on a flat and sturdy surface. Make sure no objects (e.g. curtains) can be sucked into
the rear of the fan.
• Insert the power plug [7] into the mains.
• Adjust the tilt angle by pushing the grille.
• Set the desired output speed via the control buttons:
0…STOP 1…LOW 2…MEDIUM 3…HIGH
• Always switch off the fan before moving it.
• Switch off and unplug from the mains after use.
7. Cleaning and maintenance
• Disconnect the device from the mains prior to maintenance activities.
• Clean out the parts with a soft and dry cloth. Remove stains with a damp cloth and some mild soap.
Remove soap remnants with the damp cloth. Do not use abrasives.
• Make sure no water or any other liquid enters the motor assembly [5] or the control buttons [6].
• Keep the ventilation holes of the motor assembly [5] free from dust at all times.
8. Technical specifications
CFAN0230 CFAN0245
power 50W 130W
Ø fan 30cm 45cm
airflow
speed 1 8.2m/s 11.1m/s
speed 2 9.3m/s 17.6m/s
speed 3 11.1m/s 19.1m/s
height 39cm 58cm
weight 3000g 3000g
vertical oscillation arc 130°
power supply 230Vac/50Hz
max. ambient temp 50°C
power cord length 1.8m
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulted from (incorrect) use of this device. For more info
concerning this product and the latest version of this user manual, please visit our website
www.perel.eu. The information in this manual is subject to change without prior notice.
