CAMCOLI4
V. 01 – 06/09/2012 5 ©Velleman nv
8. Choose Capture > Start Capture and click OK to confirm.
The pc now starts capturing the video file.
9. To stop, choose Capture > Stop Capture.
10. Press the snapshot button [2] to take a photo. The photo appears in a separate window. To save
the photo, choose File > Save.
11. When finished, close the Amcap program and unplug the camera from the USB port.
Software Overview
Note: Only for Windows Vista / 7.
File Set Capture File set the default folder and file name for recordings
Allocate File Space set size of recordings
Save Captured Video save recording manually to a desired location
Exit quit AmCap software
Devices list of devices that are connected to the software
Options Preview select to see live images
Video Capture Filter set parameters (white balance, exposure, etc.) and effects
(flip image, etc.)
Video Capture Pin set the size of the video window
Capture Start Capture start video capture
Stop Capture stop video capture
Set Frame Rate set the number of recorded frames per second
Set Time Limit set a maximum duration for the recording
8. Cleaning and Maintenance
• Unplug the device from the USB port.
• Wipe the device with a lint-free, soft anti-static cloth. Do not use abrasive solutions or solvents.
• Clean the gooseneck and camera with clean water after each use and let it dry before storing it.
9. Technical Specifications
pick-up element 1/6" CMOS
number of pixels 640 (H) x 480 (V)
viewing angle 56°
focus 6 cm
input interface USB 2.0
S/N ratio 46 dB
white balance auto
picture format JPEG, BMP
system requirements • Windows® XP/Vista/Windows 7/Mac OS
• free USB 2.0 port.
IP rating IP66 (camera + flexible tube)
power supply 5 VDC via USB port
dimensions
camera Ø 14 x 72 mm
flexible tube 54 cm
USB cable 200 cm
operating temperature 0 – 50°C
weight 310 g
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device.
For more info concerning this product and the latest version of this manual, please visit our
website www.velleman.eu.
The information in this manual is subject to change without prior notice.
All registered trademarks and trade names are properties of their respective owners and are used only
for the clarification of the compatibility of our products with the products of the different manufacturers.
Windows, Windows XP, Windows Vista, Windows 7, are registered trademarks of Microsoft Corporation in
